MRL02 – Roadway Light

Description

MRL02 is designed to replace up to 400W MH, it provides excellent optical performance for a variety of area and road applications. The MRL02 series can reduce energy costs by up to 65%, coupled with low maintenance costs, further reducing budget costs, meeting customers’ low budget expectations while having high-quality lighting. It also provides a photocell sensor and surge protection, as well as excellent lumen maintenance. The MRL02 is ideal for sidewalks, parking lots and roads.

Features & Benefits

Features & Benefits

  • Scalable Lumen Packages from 9,200 to 20,000 Lumens.

  • Standard CCT options (3000K, 3500K, 4000K, 5000K) with minimum 70 CRI.

  • Universal voltage operation (120 - 277V, 347 - 480V) with 1 - 10V dimming and surge protection.

  • Heavy - duty cast aluminum housing with 3G vibration rating and moisture protection.

  • Estimated 50,000 - hour LED lifespan and five - year warranty.

Specifications

Series No.

MRL02

Voltage

120-277 or 347-480 VAC

Dimmable

1-10V dimming

Light Source Type

LED chips

Color Temperature

3000K/3500K/4000K/5000K

Power

70W, 105W, 150W

Light Output

9900 lm, 14600 lm, 20000 lm

UL Listing

UL-CA-2227699-0

Operating Temperature

-40 ̊ C to 40 ̊ C ( -40°F to 104°F )

Lifespan

50,000-hour

Warranty

5 year

Application

Walkways, Parking lots, Roadways

Mounting

Pole mount

Accessories

PIR Motion Sensor (Optional), Photocell (Optional)

Specifications

Series No.

MRL02

Voltage

120-277 or 347-480 VAC

Dimmable

1-10V dimming

Light Source Type

LED chips

Color Temperature

3000K/3500K/4000K/5000K

Power

70W, 105W, 150W

Light Output

9900 lm, 14600 lm, 20000 lm

UL Listing

UL-CA-2227699-0

Operating Temperature

-40 ̊ C to 40 ̊ C ( -40°F to 104°F )

Lifespan

50,000-hour

Warranty

5 year

Application

Walkways, Parking lots, Roadways

Mounting

Pole mount

Accessories

PIR Motion Sensor (Optional), Photocell (Optional)

Specifications

Series No.

MRL02

Voltage

120-277 or 347-480 VAC

Dimmable

1-10V dimming

Light Source Type

LED chips

Color Temperature

3000K/3500K/4000K/5000K

Power

70W, 105W, 150W

Light Output

9900 lm, 14600 lm, 20000 lm

UL Listing

UL-CA-2227699-0

Operating Temperature

-40 ̊ C to 40 ̊ C ( -40°F to 104°F )

Lifespan

50,000-hour

Warranty

5 year

Application

Walkways, Parking lots, Roadways

Mounting

Pole mount

Accessories

PIR Motion Sensor (Optional), Photocell (Optional)
